Unv IP 2MP Vandal-resistant 30M Fixed Dome Camera IPC322LB-SF28-A

  • Model:  IPC322LB-SF28-A
  • SKU:                   204961
  • Condition:        New
  • Availability:      In Stock
About this Item
  • Brand: UNV
  • High quality image with 2MP, 1/2.8" CMOS sensor
  • 2MP (1920 × 1080)@30/25 fps; 720P (1280 × 720)@30/25 fps
  • Ultra 265, H.265, H.264
  • Smart IR, up to 30 m (98 ft) IR distance
  • Day/night functionality
  • 2D/3D DNR (Digital Noise Reduction)
  • IP67 protection
  • IK10 vandal resistant
  • Support PoE power supply
  • 2-Axis
AED 114 inclusive of VAT
Pay 4 interest-free payments of AED 28.50 , no interest/fees. Learn more
  • 1 year hassle free warranty claims
  • Delivery time is next working day, You can connect to support team to get exact delivery time.
Description - Unv IP 2MP Vandal-resistant 30M Fixed Dome Camera IPC322LB-SF28-A

Specification

Brand UNV
Model Number IPC322LB-SF28-A
Type Dome
weight 0.40 kg
Sensor 1/2.8"
progressive scan
2.0 megapixel
CMOS
Lens 2.8mm@F2.0
DORI Distance Lens (mm) - 2.8
Detect (m) - 43.4
Observe (m) - 17.4
Recognize (m) - 8.7
Identify (m) - 4.3
Angle of View (H) 106.7°
Angle of View (V) 57.1°
Adjustment angle Pan - 3° ~ 360°
Tilt - 0° ~ 75°
Shutter Auto/Manual
1 ~ 1/100000s
Minimum Illumination Colour - 0.01Lux ( F2.0/ AGC ON) 0Lux with IR
Day/Night IR-cut filter with auto switch (ICR)
Digital noise reduction 2D/3D DNR
S/N >52dB
IR Range Up to 30m (98ft) IR range
Wavelength 850nm
IR On/Off Control Auto/Manual
Defog Digital Defog
WDR DWDR
Video Compression Ultra 265
H.265
H.264
H.264 code profile Baseline profile
Main profile
High profile
Frame Rate Main Stream - 1080P (1920*1080); Max 30fps; 720P (1280*720); Max 30fps
Sub Stream - D1 (720*576); Max 30fps; 640*360;Max 30fps; 2CIF(704*288)
Max 30fps
CIF(352*288)
Max 30fps
Video Bit Rate 128 Kbps~16 Mbps
OSD Up to 4 OSDs
Privacy Mask Up to 4 areas
ROI Up to 8 areas
Motion Detection Up to 4 areas
White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction 2D/3D DNR
Smart IR Supported
Flip Normal/Vertical/Horizontal/180°
Dewarping N/A
HLC Supported
BLC Supported
Protocols IPv4
IGMP
ICMP
TCP
UDP
DHCP
RTP
RTSP
RTCP
DNS
DDNS
NTP
UPnP
HTTP
Compatible Integration API
Client EZStation
Network 10/100M Base-TX Ethernet
Certifications CE - EN 60950-1
UL - UL60950-1
FCC - FCC Part 15
Power DC 12V±25%
PoE (IEEE 802.3af)
Power consumption
Material Metal + Plastic
Working Environment -30°C ~ 60°C (-22°F ~ 140°F)
Humidity - ≤95% RH (non-condensing)
Strorage Environment -30°C ~ 60°C (-22°F ~ 140°F)
Humidity - ≤95% RH (non-condensing)
Surge Protection 4KV
Ingress Protection IP67
Vandal Resistant IK10
Reset Button N/A
Package Dimension (W, H, L ) in cm 10.9 x 8.1 x 8.1
Warranty 1 Year Warranty
