| Camera |
| Sensor |
1/2.7″, 5.0 megapixel, progressive scan, CMOS |
| Lens |
4.0mm@F2.0 |
6.0mm@F2.0 |
| DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
| 4.0 |
60 |
24 |
12 |
6 |
| Angle of View (H) |
79.7° |
50.5° |
| Angle of View (V) |
51.8° |
35.9° |
| Angle of View (O) |
98.0° |
62.1° |
| Adjustment angle |
Pan: 0° ~ 360° |
Tilt: 0° ~ 90° |
Rotate: 0° ~ 360° |
| Shutter |
Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination |
Colour: 0.01Lux (F2.0, AGC ON)
0Lux with IR on |
| Digital noise reduction |
2D/3D DNR |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>52dB |
| IR Range |
Up to 30m (98ft) IR range |
| WDR |
DWDR |
| Video |
| Video Compression |
Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile |
| Frame Rate |
Main Stream: 5MP (2592*1944), Max 20fps;
Sub Stream: 720P (1280×720), Max 20fps |
| HLC |
Supported |
| BLC |
Supported |
| OSD |
Up to 4 OSDs |
| Privacy Mask |
Up to 4 areas |
| ROI |
Up to 2 areas |
| Motion Detection |
Up to 4 areas |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS |
| Compatible Integration |
ONVIF (Profile S, Profile T), API |
| Interface |
| Network |
10/100M Base-TX Ethernet |
| General |
| Power |
DC 12V±25%, PoE (IEEE 802.3af) |
| Power consumption: Max 4W |
| Dimensions (L × W × H) |
167.3 × 62.9 × 62.7mm (6.6” × 2.5” × 2.5”) |
| Weight |
0.37kg (0.81lb) |
| Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Ingress Protection |
IP67 |
| Reset Button |
Supported |
