Omada Cloud Essentials — A Free and Easy Cloud-Based Network Management
Omada Cloud Essentials is a free, easy-to-use version of the Omada Cloud-based Controller. It provides cloud-based centralized management and monitoring for the Omada networking system, covering access points, switches, and gateways, ideal for surveillance networks and small businesses.
| Category |
Specification |
| Hardware Features |
|
| Interface |
• 24× 10/100/1000 Mbps PoE+ RJ45 Ports (802.3af/at) • 2× 10/100/1000 Mbps RJ45 Ports • 2× Gigabit SFP Slots • Auto-Negotiation/Auto MDI/MDIX |
| Fan Quantity |
2 |
| Installation |
Rackmountable |
| Physical Security Lock |
Yes |
| Power Supply |
100–240V AC, 50/60Hz |
| PoE Standards |
802.3af PoE, 802.3at PoE+ |
| PoE Ports |
24 RJ45 Ports |
| PoE Budget |
384W total, 30W max per port |
| PoE Features |
Fast PoE, Perpetual PoE, PoE Auto Recovery, up to 250m transmission |
| Dimensions (W×D×H) |
440 × 330 × 44 mm (17.3 × 13.0 × 1.7 in) |
| Surge Protection |
±6kV |
| Performance |
|
| Switching Capacity |
56 Gbps |
| Packet Forwarding Rate |
29.76 Mpps |
| MAC Address Table |
8K entries |
| Packet Buffer Memory |
4 Mbit |
| Jumbo Frame |
15 KB |
| Software Features |
|
| QoS |
• Port-based, 802.1p, DSCP QoS • 8 Priority Queues • WRR Scheduling • Queue Weight Config • Bandwidth Control • Storm Control (kbps/pps, Broadcast/Multicast/Unknown-Unicast) |
| L2 Features |
• Static Link Aggregation • Loop Prevention/Loopback Detection • 802.3x Flow Control • Port Mirroring (One-to-One, Many-to-One, Ingress/Egress/Both) • Port Statistics • 802.1ab LLDP |
| L2 Multicast |
• IGMP Snooping v1/v2/v3 • Fast Leave |
| VLAN |
• MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN (32 VLAN groups, 4K VID) |
| Transmission Method |
Store-And-Forward |
| Management |
|
| Omada App |
Yes (with Omada Hardware, Cloud-Based, or Software Controller) |
| Centralized Management |
• Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller |
| Cloud Access |
Yes (with Controller) |
| Zero-Touch Provisioning |
Yes (with Cloud-Based Controller) |
| Other Management |
• Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery • Batch Config & Firmware Upgrade • Unified Configuration |
| Others |
|
| Certification |
FCC, CE, RoHS |
| Package Contents |
• ES228GMP Switch • Power Cord • Mounting Brackets • Rubber Feet • Screws • Installation Guide |
| Operating Temp |
-5℃ to 45℃ (23℉ to 113℉) |
| Storage Temp |
-40℃ to 70℃ (-40℉ to 158℉) |
| Operating Humidity |
10% to 90% (non-condensing) |
| Storage Humidity |
5% to 90% (non-condensing) |
