| Processor type: |
Intel Xeon Scalable processors, 1st and 2nd generations |
| Processor name: |
Intel Xeon Scalable processors, 1st or 2nd generation |
| Processor family: |
1st generation: Intel Xeon Scalable 8100 series, Intel Xeon Scalable 6100 series, Intel Xeon Scalable 5100 series, Intel Xeon Scalable 4100 series, Intel Xeon Scalable 3100 series, 2nd generation: Intel Xeon Scalable 8200 series, Intel Xeon Scalable 6200 series, Intel Xeon Scalable 5200 series, Intel Xeon Scalable 4200 series, Intel Xeon Scalable 3200 series |
| Processor number: |
1 or 2 |
| Processor core available: |
28 or 26 or 24 or 22 or 20 or 18 or 16 or 14 or 12 or 10 or 6 or 8 or 4, depending on model |
| Processor cache: |
38.50 MB L3 – 8.25 MB L3, depending on model |
| Processor speed: |
3.9 GHz, maximum depending on processor |
| Power supply type: |
HPE Flexible Slot Redundant Power Supply modules 500W / 800W / 1600W, depending on model SKU, or HPE Standard 500W Non-Hot-Plug/non-RPS Power Supply (ordering limited to non-EU/EMEA countries/regions) |
| Expansion slots: |
8-slots (x 16, x 8, x 16, x 8, x 16, x 8, x 16, x 8) as standard in 2P model. For detail reference QuickSpecs. |
| Maximum memory: |
3.0 TB with 128 GB DDR4 DIMM |
| Memory standard: |
32 GB (1 x 32 GB) RDIMM or depending on model |
| Memory slots: |
24 DIMM slots |
| Memory type: |
HPE DDR4 SmartMemory |
| Memory protection features: |
Advanced ECC Memory Online Spare Mode Memory Lock Step Mode |
| Included hard drives: |
None Ship Standard |
| Optical drive type: |
Optional DVD-ROM or DVD-RW. Optional via Slim-line ODD Bay Kit. Optional external support is available too. Optional Half-Height RDX or Tape, up to 2. Optional via Media Drive Support Kit. |
| System fan features: |
Depending on model SKU. Standard 2 fans, none-hot-plug. Optional 4 additional fans, hot-plug and N+1 redundancy. |
| Network controller: |
HPE Ethernet 1Gb 4-port 369i Adapter |
| Storage Controller: |
1 HPE Smart Array S100i and/or 1 HPE Smart Array P408i-a SR Gen10 and/or 1 HPE Smart ArrayE208i-a Gen10, depending on model |
| Product dimensions (metric): |
46.25 x 64.8 x 17.4 cm |
| Weight: |
21 kg |
| Infrastructure management: |
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download)(standard), HPE iLO Advanced, and OneView Advanced (optional) |
| Warranty: |
3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. |
| Drive supported: |
24 SFF SAS/SATA HDD/SSD, or 16 SFF SAS/SATA HDD/SSD and 8 SFF NVMe SSD. 12 LFF SAS/SATAHDD/SSD or 12 LFF NHP SATA HDD, depending on model. Upgrade option kits are available. |
