| Processor Name: |
Intel |
| Processor family: |
Intel Xeon Scalable 8100/8200 series – Intel Xeon Scalable 3100/3200 series |
| Number of processors: |
2, maximum depending on model |
| Processor core available: |
4 to 28 core, depending on model |
| Processor cache: |
8.25 – 38.50 MB L3, depending on processor |
| Processor speed: |
3.9 GHz, maximum depending on processor |
| Expansion slots: |
3 |
| Maximum memory: |
3.0 TB with 128 GB DDR4, 6.0 TB with HPE 512GB 2666 Persistent Memory Kit |
| Memory, standard: |
3.0 TB (24 x 128 GB) LRDIMM, 6.0 TB (12 x 512 GB) HPE Persistent Memory |
| Memory slots: |
24 DIMM slots |
| Memory type: |
HPE DDR4 Smart Memory and Intel Optane persistent memory 100 series for HPE, depending on model |
| System fan features: |
Hot-plug redundant standard |
| Network controller: |
Embedded 4 x 1GbE Ethernet Adapter (select models) or HPE FlexibleLOM and optional PCIe stand-upcards, depending on model |
| Storage controller: |
HPE Smart Array S100i and/or HPE Essential or Performance RAID controllers, depending on model |
| Product Dimensions (metric): |
SFF Chassis: 4.29 x 43.46 x 70.7 cm, LFF Chassis: 4.29 x 43.46 x 74.98 cm |
| Weight: |
13.04 kg minimum, 16.78 kg maximum |
| Infrastructure management: |
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional- HPE iLO Advanced, and HPE OneView Advanced (require licenses) |
| Warranty: |
3/3/3 – Server Warranty includes three years of parts, three years of labor, three years of onsite support coverage. |
| Drive supported: |
4 LFF SAS/SATA, 8 SFF SAS/SATA + 2 NVMe, 10 SFF SAS/SATA, 10 SFF NVMe, 1 SFF or 1 Dual UFFrear drive optional depending on model |
