| Specifications |
|---|
| Model | CS-H3-R100-1J5WKFL |
|---|
| General |
|---|
| Dimensions | 75.5 × 75.5 × 155 mm (2.97
× 2.97 × 6.10 inch) |
|---|
| Package Dimensions | 227 × 100 × 92 mm (8.94 ×
3.94 × 3.62 inch) |
|---|
| Weight | Net weight: 433 g (15.27
oz) With package: 652 g (23.00 oz) |
|---|
| IP Grade | IP67 |
|---|
| Operating Conditions | -30 °C ~ 60 ºC (-22 °F ~
140 °F ) Humidity 95% or less (non-condensing) |
|---|
| Camera |
|---|
| Image Sensor | 1/2.7”Progressive Scan
CMOS |
|---|
| Shutter Speed | Self-adaptive shutter |
|---|
| Lens | 2.8mm @ F2.0, viewing
angle: 114° (Diagonal), 96° (Horizontal), 51° (Vertical) 4mm @ F2.0,
viewing angle: 95° (Diagonal), 80° (Horizontal), 42° (Vertical) |
|---|
| Minimum Illumination | 0.01 lux @ (F2.0, AGC ON),
0 Lux with IR |
|---|
| Lens Mount | M12 |
|---|
| Day / Night Switch | IR-Cut filter with
auto-switching |
|---|
| DNR | 3D DNR |
|---|
| WDR | Digital WDR |
|---|
| BLC | Supports |
|---|
| IR Night Vision Distance | Up to 98 ft / 30 m |
|---|
| Video & Audio |
|---|
| Max. Resolution | 2880 × 1620 pixels |
|---|
| Frame Rate | Max: 30fps; Self-Adaptive
during network transmission |
|---|
| Video Compression | H.265 / H.264 |
|---|
| Video Bit Rate | Quad HD+; Full HD; HD;
Standard. Adaptive bit rate. |
|---|
| Audio Bit Rate | Self-Adaptive |
|---|
| Max. Bitrate | 2.5 Mbps |
|---|
| Network |
|---|
| Wi-Fi Standard | IEEE802.11b, 802.11g,
802.11n |
|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
|---|
| Channel Bandwidth | Supports 20 MHz |
|---|
| Security | 64 / 128-bit WEP, WPA /
WPA2, WPA-PSK / WPA2-PSK |
|---|
| Transmission Rate | 11b: 11 Mbps, 11g: 54 Mbps,
11n: 150 Mbps |
|---|
| Wi-Fi Pairing | AP Pairing |
|---|
| Protocol | EZVIZ Cloud Proprietary
Protocol |
|---|
| Interface Protocol | EZVIZ Cloud Proprietary
Protocol |
|---|
| Wired Network | RJ45 × 1 (10M / 100M
Adaptive Ethernet Port) |
|---|
| Function |
|---|
| Detection | AI-Powered Human / Vehicle
Shape Detection, Waving-Hand Detection, Motion Detection |
|---|
| Customized Alert Area | Supports |
|---|
| Integration | Works with Alexa, Google
Assistant, IFTTT |
|---|
| General Function | Anti-Flicker, Dual-Stream,
Heart Beat, Mirror Image, Password Protection, Watermark |
|---|
| Storage |
|---|
| Local Storage | Supports microSD card (Up
to 512 GB) |
|---|
| Cloud Storage | Supports EZVIZ CloudPlay
storage (Subscription required) |
|---|
| Power |
|---|
| Wiring | Hard-Wired |
|---|
| Power Supply | DC 12V / 1A |
|---|
| Power Consumption | Max. 8W |
|---|
