Made for the great outdoors
Wi-Fi and power can be a headache when it comes to outdoor protection. The EB8 4G changes the game by operating with a large battery and 4G network. The camera is weatherproof against rain and snow, and can stay charged using sunlight through a compatible solar panel.
1 Smarter detections for essential activities
The EB8 4G is designed to provide smart notifications on detected activities. You can set the camera to detect all kinds of motion – including running animals – or enable the smart human motion feature to auto-track human activities.
2 360° plus 2K, for far less blind spots
A bigger space needs a wider view, and that’s where the EB8 4G comes in handy. It can pan and tilt to take in a 360-degree field-of-view, and render details in 2K resolution to capture crucial moments clearly.
| Specifications |
|---|
| Model | CS-EB8 (3MP,4GA) |
|---|
| Camera |
|---|
| Image Sensor | 1/2.8” 3-Megapixel
Progressive Scan CMOS Sensor |
|---|
| Minimum Illumination | 0.01 Lux @(F1.6, AGC ON), 0
Lux with IR |
|---|
| Shutter Speed | Self-adaptive shutter |
|---|
| Lens | Viewing angle: 100°
(Diagonal), 83° (Horizontal), 44° (Vertical) |
|---|
| PT Angle | Pan: 340, Tilt: 65° |
|---|
| Day & Night | IR-cut filter with auto
switch |
|---|
| DNR | 3D DNR |
|---|
| Night Vision Distance | IR 15 m，Color Night Vision
15 m |
|---|
| Video & Audio |
|---|
| Max Resolution | 2304 x 1296 |
|---|
| Frame Rate | Max. 15fps; Self-Adaptive
during network transmission |
|---|
| Video Compression | H.265 / H.264 |
|---|
| Video Bit Rate | Quad-HD;Full- HD; Hi-Def.
Adaptive bit rate. |
|---|
| Audio Bit Rate | Self-Adaptive |
|---|
| Max. Bitrate | 1.5 Mbps |
|---|
| Network |
|---|
| Frequency Bands | EU: LTE FDD: B1/B3/B7/B8/B20/B28 LTE TDD: B38/B40 LA： LTE FDD: B1/B2/B3/B4/B5/B7/B8/B12/B17/B20/B28/B66 LTE TDD: B38/B40 |
|---|
| Function |
|---|
| Smart Alarm | Smart human motion
detection |
|---|
| GPS | Supports |
|---|
| Two-way Talk | Supports |
|---|
| General Function | Anti-Flicker, Heart Beat,
Password Protection, Watermark |
|---|
| Storage |
|---|
| Local Storage | Supports microSD Card (Up
to 512G) |
|---|
| Cloud Storage | EZVIZ cloud storage |
|---|
| General |
|---|
| Operating Conditions | -20 °C to 50 °C (-4 °F to
122 °F ), humidity 95% or less (Non-condensing) |
|---|
| IP Grade | IP65 |
|---|
| Power Supply | DC 5V/2A (Adapter needs to
be purchased separately) |
|---|
| Battery Capacity | 10400 mAh |
|---|
| Power Consumption | Max. 10W |
|---|
| Product Dimensions | 183 × 116 × 166 mm (7.20 ×
4.57 × 6.52 inch) |
|---|
| Packaging Dimensions | 216 × 145 × 203 mm (8.50 ×
5.71 × 7.99 inch) |
|---|
| Weight | Net weight: 835 g (26.8 Oz)
With package: 1072 g (34.4 Oz) |
|---|
