| Processor: |
One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 cores |
| Memory: |
• Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s • Supports unregistered ECC DDR4 DIMMs only • NOTE: For Pentium processor, maximum memory speed supported is 2666 MT/s |
| Storage Controller: |
• Internal controllers (RAID): PERC H755, PERC H345, HBA355i, S150 • Internal Boot: USB, Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs • External HBAs (non-RAID): HBA355e |
| Drive bays: |
4 x 3.5-inch cabled SAS/SATA (HDD/SSDs) max 30.72 TB |
| Power supplies: |
• 300W Bronze 100-240 VAC, cabled • 400W Platinum 100-240 VAC, cabled (available only from Dec’21) |
| Fans: |
One cabled fan |
| Dimensions: |
• Height: 360 mm (14.17 inches) • Width: 175 mm (6.88 inches) • Depth: 453.75 mm (17.86 inches) with bezel |
| Form Factor: |
4U mini tower server |
| Embedded management: |
• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module |
| Bezel: |
Security bezel |
| OpenManage Software: |
• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin |
| Mobility: |
OpenManage Mobile |
| Integrations and Connections: |
OpenManage Integrations: BMC Truesight, Microsoft System Center, Red Hat Ansible Modules, VMware vCenter and vRealize Operations Manager, OpenManage Connections: IBM Tivoli Netcool/OMNIbus, IBM Tivoli Network Manager IP Edition, Micro Focus Operations Manager, Nagios Core, Nagios XI |
| Security: |
• Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ |
| Embedded NIC: |
2 x 1 GbE LOM |
| Ports: |
• Front Ports: 1 x iDRAC Direct (Micro-AB USB) port, 1 x USB 3.0, Internal Ports, 1 x USB 3.0 (optional) • Rear Ports, 5 x USB 2.0, 1 x iDRAC ethernet port, 1 x USB 3.0, 1 x Serial port, 1 x VGA |
| PCIe: |
4 PCIe slots: 1 x16 Gen4 ( x 16 connector) full height, half length • 1 x 4 Gen4 ( x 8 connector) full height, half length • 1 x 4 Gen3 ( x 8 connector) full height, half length • 1 x 1 Gen3 ( x 1 connector) full height, half length |
