| Processor: |
Up to two 3rd Generation Intel Xeon Scalable processors, with up to 24 cores per processor |
| Memory: |
Memory 16 DDR4 DIMM slots, supports RDIMM max 1 TB, speeds up to 2933 MT/s |
| Storage Controller: |
• Internal controllers (RAID): PERC H345, PERC H355, HBA355i, PERC H745, PERC H755, S150 • Internal Boot: Internal Dual SD Module or Boot Optimized Storage Subsystem (BOSS-S1): HWRAID 2 x M.2 SSDs or USB • External PERC (RAID): PERC H840 • External HBA (non-RAID) HBA355e |
| Drive Bays: |
Front bays: • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 61.4 TB |
| Power Supplies: |
• 600W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant • 800W Platinum Mixed Mode (100-240Vac or 240Vdc) hot swap redundant • 1100W -48Vdc hot swap redundant (CAUTION: only works with -48Vdc to -60Vdc power input) |
| Cooling options: |
Air cooling |
| Fans: |
• Standard (STD) fans or High performance SLVR fans • Up to seven cold swap fans |
| Dimensions: |
• Height – 42.8 mm (1.7 inches) • Width – 482 mm (18.97 inches) • Depth – 734.95 mm (28.92 inches) – without bezel, 748.79 mm (29.47 inches) – with bezel |
| Form Factor: |
1U Rack Server |
| Embedded Management: |
• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module • Quick Sync 2 wireless modulen |
| Bezel: |
Optional LCD bezel or security bezel |
| OpenManage Software: |
• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin |
| Mobility: |
OpenManage Mobile |
| Integrations and Connections: |
OpenManage Integrations – BMC Truesight, Microsoft System Center, Red Hat Ansible Modules, VMware vCenter and vRealize Operations Manager • OpenManage Connections – IBM Tivoli Netcool/OMNIbusnIBM Tivoli Network Manager IP Edition, Micro Focus Operations ManagernNagios CorenNagios XI |
| Security: |
• Cryptographically signed firmwarenSecure BootnSecure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China Nation |
| Embedded NIC: |
Embedded NIC |
| Network Options: |
1 x OCP 3.0 |
| GPU Options: |
NA |
| Ports: |
Front Ports: 1 x Dedicated iDRAC Direct micro-USB, 1 x USB 3.0, 1 x VGA • Internal Ports: 1 x USB 3.0 (optional) • Rear Ports: 1 x USB 2.0, 1 x Serial (optional), 1 x iDRAC ethernet port, 1 x USB 3.0, 2 x Ethernet, 1 x VGA |
| PCIe: |
2 x PCIe Gen4 slots + PCIe Gen, 2 x 16 Gen4 ( x 16 connector) low profile, half length, 1 x 4 Gen3 (x 8 connector) low profile, half length |
| Operating System and Hypervisors: |
Canonical Ubuntu Server LTS, Citrix Hypervisor, Microsoft Windows Server with Hyper-V, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi |
| OEM-ready version available: |
From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. |
