> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG
decoding formats.
> Max. decoding capability: 32 × 1080p@30 fps or 32 × 2MP@30 fps.
> Max. 384/384/384 Mbps incoming/recording/outgoing bandwidth.
> Supports IP cameras with a resolution up to 32 MP.
> Supports AcuPick with up to 32 channels.
> Supports N+M cluster,iSCSI.
> AI by Recorder supports 2-channel face detection and recognition,
up to 20 face databases and 20,000 face images; 4-channel
perimeter protection; 8-channel SMD Plus.
> AI by Camera supports face detection and recognition, perimeter
protection, SMD Plus, metadata, ANPR, stereo analysis, heat map,
and people counting.
> Supports EPTZ, and one-click arming and disarming.
Specification
|
System
|
|
Main Processor
|
Industrial-grade processor
|
|
Operating System
|
Embedded Linux
|
|
Operating Interface
|
Web, Local GUI
|
|
AI
|
|
AI by Recorder
|
Face detection; face recognition; perimeter protection; SMD Plus
|
|
AI by Camera
|
Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD Plus; stereo analysis; crowd distribution; people counting; ANPR; vehicle density; heat map
|
|
AcuPick AI by Camera + Recorder
|
Max. 32-channel, 1 combined event per channel/s
|
|
Perimeter Protection
|
|
Perimeter Performance AI by Recorder (Number of Channels)
|
4 channels, 10 IVS rules for each channel
|
|
Perimeter Performance of AI by Camera (Number of Channels)
|
All channels (16 targets/s)
|
|
Face Detection
|
|
Face Attributes
|
Gender; age group; glasses; expressions; face mask; beard
|
|
Face Detection Performance of AI by Recorder (Number of Channels)
|
2 channels (up to 12 face images/s each channel)
|
|
Face Detection Performance of AI by Camera (Number of Channels)
|
16 channels
|
|
Face Recognition
|
|
Face Database Capacity
|
Up to 20 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
|
|
Face Recognition Performance of AI by Recorder (Number of Channels)
|
1. 16-channel FD (by camera) + FR (by recorder), image stream: 16 face images/s
2. 2-channe FD (by recorder) + FR (by recorder), video stream: 12 face images/s
|
|
Face Recognition Performance of AI by Camera (Number of Channels)
|
16 channels
|
|
SMD Plus
|
|
SMD Plus by Recorder
|
8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change
|
|
SMD Plus by Camera
|
All channels (32 targets/s)
|
|
Video Metadata
|
|
Metadata Performance of AI by Camera (Number of Channels)
|
8 channels
|
|
Human Attributes
|
Top color, top type, bottom color, bottom type, hat, bag, age, gender and umbrella
|
|
Motor Vehicle Attributes
|
License plate, plate color, vehicle body, vehicle model, vehicle logo, calling, seatbelt, vehicle interior, vehicle registration location.
|
|
Non-motor Vehicle Attributes
|
Vehicle model, vehicle color, number of persons, helmet.
|
|
Vehicle License Plate Comparison
|
|
ANPR by Camera (Number of Channels)
|
All channels (8 targets/s)
|
|
License Plate Database Capacity
|
1. Create up to 20,000 plate numbers.
2. Blocklist and allowlist
|
|
Audio and Video
|
|
Access Channel
|
64 channels
|
|
Network Bandwidth
|
AI disabled: 384 Mbps incoming, 384 Mbps recording and 384 Mbps outgoing
AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing
|
|
Resolution
|
32 MP;24 MP;16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF
|
|
Decoding Capability
|
AI disabled: 2-channel 32 MP@25 fps; 2-channel 24 MP@25 fps; 4-channel 16 MP@30 fps; 5-channel 12 MP@30 fps; 8-channel 8 MP@30 fps; 10-channel 6 MP@30 fps; 12-channel 5 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps
AI enabled: 1-channel 32 MP@25 fps; 1-channel 24 MP@25 fps; 2-channel 16 MP@30 fps; 4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 6 MP@30 fps; 8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps
|
|
Video Output
|
2 VGA, 2 HDMI
VGA:1920 × 1080, 1280 × 1024, 1280 × 720
HDMI:3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Heterogeneous video source output for HDMI1 and HDMI2
Simultaneous video source output for VGA1 and HDMI1
Simultaneous video source output for VGA2 and HDMI2
|
|
Multi-screen Display
|
Main screen: 1/4/8/9/16/25/36/64
Sub screen: 1/4/8/9/16
|
|
Third-party Camera Access
|
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha
|
|
Compression Standard
|
|
Video Compression
|
Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
|
|
Audio Compression
|
|
