| System |
| Main Processor |
Industrial-grade processor |
| Operating System |
Embedded Linux |
| Operating Interface |
Web, Local GUI |
| AI |
| AI by Recorder |
SMD Plus |
| AI by Camera |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
| Perimeter Protection |
| Perimeter Performance of AI by Camera (Number of Channels) |
6 channels |
| Face Detection |
| Face Attributes |
Gender; age group; glasses; expressions; face mask; beard |
| Face Detection Performance of AI by Camera |
6 channels |
| Face Recognition |
| Performance of AI by Camera (Number of Channels) |
6 channels |
| SMD Plus |
| SMD Plus by Recorder |
2 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera |
6 channels |
| Audio and Video |
| Access Channel |
32 channels |
| Network Bandwidth |
AI disabled: 160 Mbps incoming, 128 Mbps recording and 60 Mbps outgoing AI enabled: 80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing |
| Resolution |
12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF; QCIF |
| Decoding Capability |
AI disabled: 1-channel 12 MP@30 fps; 2-channel 8 MP@30 fps; 3-channel 5 MP@30 fps; 4-channel 4 MP@30 fps; 8-channel 1080p@30 fps AI enabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 7-channel 1080p@30 fps |
| Third-party Camera Access |
ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
| Compression Standard |
| Video Compression |
Smart H.265+; H.265; Smart H.264+; H.264 |
| Audio Compression |
G.711a; G.711u; PCM; G726 |
| Network |
| Network Protocol |
HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP; Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.) |
| Mobile Phone Access |
iOS; Android |
| Interoperability |
ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK |
| Browser |
Chrome; IE; Safari; Edge; Firefox |
| Recording Playback |
| Multi-channel Playback |
Up to 16 channels |
| Record Mode |
General, motion detection; intelligent; alarm |
| Backup Method |
USB device and network |
| Playback Mode |
Instant playback, general playback, event playback, tag playback, smart playback |
| Storage |
| Disk Group |
Yes |
| Alarm |
| General Alarm |
Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm |
| Anomaly Alarm |
Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception |
| Intelligent Alarm |
Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map |
| Alarm Linkage |
Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email |
| Port |
| Audio Input |
1-channel RCA |
| Audio Output |
1-channel RCA |
| Alarm Input |
4 channels |
| Alarm Output |
2 channels (1-channel 12 V 1 A output） |
| Disk Interface |
2 SATA ports. Each disk can contain up to 20 TB. This limit varies depending on the environment temperature. |
| USB |
2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
| HDMI |
1 |
| VGA |
1 |
| Network Port |
1 (10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply |
12 VDC, 4 A |
| Power Consumption |
Total output of NVR is <10 W(without HDD) |
| Net Weight |
1.49 kg (3.28 lb) |
| Gross Weight |
2.77 kg (6.11 lb) |
