Specification
·
4 megapixel 1/2.7" dual CMOS sensor
·
Video formats AI-H.265, AI-H.264, Smart H.265+, Smart H.264+,
H.265, H.264, H.264, MJPEG
·
Digital resolution: 8MP (4096x1860), 6MP (3632x1632), 4MP
(3040x1368), 1.6MP (1920x860), 1200x530, 960x432
·
Stream 1: 8MP (1~20 ips)
·
Stream 2: 1200x530 (1~20 fps)
·
Stream 3: 1.6MP (1~20 fps)
·
Day/night mode with removable mechanical filter (ICR)
·
Smart Light: 2 IR leds (25 meters) + 2 warm light leds (20
meters)
·
0.005 lux F1.4 (color), 0.0005 lux F1.4 (B/W), 0 lux with
activated illumination
·
2.8 mm fixed optics
·
Angle of view: 180°(H), 86°(V)
·
Imaging modes: BLC, HLC, WDR 120dB, SSA, 3D-NR, Defog
·
White balance with 6 modes
·
Automatic gain control
·
Supports 4-zone videosensor, 4 regions of interest (ROI) and
4-zone privacy masking
·
Perimeter protection with cross-line detection and intrusion
detection (both modes support human/vehicle classification)
·
SMD 4.0: Less false alarms, longer detection distance
·
Built-in dual microphone and dual speaker
·
1 input / 1 output RCA audio
·
1 alarm input / 1 alarm output
·
MicroSD card slot up to 256GB (not included)
·
Network interface: RJ45 (10/100 Base-T)
·
Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP,
RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast,
ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
·
ONVIF (Profile S/G/T), CGI, SDK and API support
·
Up to 20 users
·
Remote viewing via IE8 and later, Chrome and Firefox browsers
·
Smart PSS Lite, DSS, DMSS, Smart PSS Lite management software
·
Compatible with iOS and Android devices
·
Power supply: 12V DC (±30%) / PoE (802.3af)
·
Maximum power consumption: 9W (12V), 10.3W (PoE)
·
Storage temperature from -40°C ~ +60°C
·
Operating temperature from -40°C ~ +60°C
·
Relative humidity: ≤95%.
·
IP67 protection rating
·
Metal housing
·
Dimensions: 99 (W) x 78 (H) x 183,1 mm
·
Net weight: 695 g
·
Gross weight: 870 g
·
3AXIS: 0°~360° (Pan), 0°~77° (Tilt), 0°~360° (Rotation)
