> 4-MP 1/3" CMOS image sensor, excellent low luminance performance and high definition of images.
> Outputs max. 4 MP (2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED, max. IR distance: 60 m.
> ROI, SMART H.264 +/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card
error, network disconnection, IP conflict, illegal access, and voltage
detection.
> Alarm: 1 in, 1 out (Only - ZAS supports ); audio: 1 in, 1 out (Only - ZAS supports); max. 256 G Micro SD card. built-in Mic.
> 12 VDC/PoE power supply facilitates installation.
> IP67, IK10 (optional) protection.
> SMD 4.0, AI SSA.
Specification
| AI |
WizSense Series |
| POWER / CONSUMPTION |
12Vdc and PoE |
| IVS ANALYTICS |
Tripwire and Intrusion |
| COMPRESSION (VIDEO/AUDIO) |
H.265+/H.265/H.264+/H.264/MJPEG (Sub Stream) and PCM/G.711a/ G.711Mu /G.726/G.723 |
| SWITCHING |
Day - Night with ICR Filter |
| CAMERA FUNCTIONS |
WDR(120dB), 3DNR, HLC, BLC |
| AUXILIARY INTERFACE |
Micro SD (up to 256GB) |
| IR LEDs |
IR LEDS (Up to 60m) |
| MAX. RESOLUTION / IPS |
4MP@25IPS |
| MIN. LIGHTING |
0.005Lux@F1.5 |
| PROTECTION |
IP67 |
| SENSOR |
1/3" CMOS 4MP |
| SUPPORTS SMD |
SMD 4.0 |
| VIDEO STREAM |
Main 4MP@25IPS / 2nd D1 / 3rd 1080P |
| TEMPERATURE |
From -30ºC at +60ºC (95% HR) |
| OPTICS |
Motorized Varifocal 2.7-13.5mm |
