> 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition
image.
> Outputs max. 5 MP (2960 × 1668) @20 fps, and supports 2688×1520
(2688 × 1520) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light and IR LED, the max. IR light distance is 60 m and
max. warm light is 50 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the
classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, audio
detection, no SD card, SD card full, SD card error, network
disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD
card; built in MIC.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 (optional) protection.
> SMD Plus.
Specificatio
2 megapixel 1/2.8" CMOS sensor
·
Compression Formats: Smart H.265+, Smart H.264+, H.265, H.264,
MJPEG
·
Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P
(1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
·
Stream 1: 1080P (1~25/30 ips)
·
Stream 2: D1 (1~25/30 fps)
·
Day/night mode with removable mechanical filter
·
Smart Light: 2 IR leds (60 meters) + 2 warm light leds (50
meters)
·
0.002 lux F1.6 (color), 0.0002 lux F1.6 (B/W), 0 lux IR On
·
3.6 mm fixed optics
·
Angle of view: 84°(H), 44°(V), 105°(D)
·
Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror.
·
White balance with 6 modes
·
Automatic and manual gain control
·
Supports 4-zone videosensor, 4 regions of interest (ROI) and
4-zone privacy masking
·
Perimeter protection with cross-line detection and intrusion
detection (both modes support human/vehicle classification)
·
SMD Plus
·
Built-in microphone
·
1 audio input / 1 audio output
·
1 alarm input / 1 alarm output
·
MicroSD card slot up to 256GB (not included)
·
Network interface: RJ45 (10/100 Base-T)
·
Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP,
RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP,
P2P
·
ONVIF (Profile S/T/G), CGI, SDK and API support
·
Up to 6 users
·
Remote viewing via IE, Chrome and Firefox browsers
·
SmartPSS Lite, DSS, DMSS management software
·
Compatible with IOS and Android mobile devices
·
Power supply: 12V DC / PoE (802.3af)
·
Power consumption: 5.8W (12V) / 6.9W (PoE)
·
Storage temperature from -40°C ~ +60°C
·
Operating temperature from -40°C ~ +60°C
·
Relative humidity: ≤95%.
·
IP67 protection rating
·
Metal housing
·
Dimensions: 90.7 (W) x 90.7 (H) x 238.5 mm (W) x 90.7 (H) x
238.5 mm (2.5 x 2.8 in)
·
Net weight: 720 g
·
Gross weight: 950 g
·
3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
