> 4-MP 1/2.9" CMOS image sensor, low luminance, and high definition
image.
> Outputs max. 4 MP (2688 × 1520)@20 fps, and 4 MP (2560 ×
1440)@25/30 fps by default.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in IR LED and warm light, and the max. IR illumination distance is
30 m, the max. warm light distance is 30 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the
classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, video tampering, audio
detection, no SD card, SD card full, SD card error, network
disconnection, IP conflict, illegal access, and voltage detection.
> Supports max. 256 G Micro SD card; built-in Mic; built-in speaker;
support two-way talk.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> Sound and light alarm
> SMD Plus.
> One-tap arming/disarming.
Specification
| Camera |
| Image Sensor | 1/2.9" CMOS |
| Max. Resolution | 2688 (H) × 1520 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.004 lux@F1.0 (Color, 30 IRE)
0.0004 lux@F1.0 (B/W, 30 IRE)
0 lux (Illuminator on) |
| S/N Ratio | >56 dB |
| Illumination Distance | Up to 30 m (98.43 ft) (IR )
Up to 30 m (98.43 ft) (Warm Light) |
| Illuminator On/Off Control | Auto;Manual |
| Illuminator Number | 2 (IR LED); 2 (Warm light) |
| Angle Adjustment | Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F1.0 |
| Field of View | 2.8 mm: H: 101.6°; V: 54.8°; D: 122.1°
3.6 mm: H: 84°; V: 45.6°; D: 98.9° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 1.4 m (4.59 ft)
3.6 mm: 2.0 m (6.56 ft) |
| DORI Distance | Lens | |
