> 4-MP 1/2.9" CMOS image sensor, low luminance, and high definition
image.
> Outputs max. 4 MP (2688 × 1520)@20 fps, and supports 2560 × 1440
@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light and IR LED, the max. IR light distance is 60 m and
max. warm light is 50 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable
to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the
classification and accurate detection of vehicle and human).
> Abnormality detection: Motion detection, video tampering, audio
detection, no SD card, SD card full, SD card error, network
disconnection, IP conflict, illegal access, and voltage detection.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD
card; built in MIC.
> 12 VDC/PoE power supply, easy for installation.
> IP67, IK10 (optional) protection.
> SMD Plus.
Specification
| Standard: |
TCP/IP |
| Sensor: |
1/2.9 " Progressive Scan CMOS |
| Matrix size: |
4 Mpx |
| Resolution: |
2688 x 1520 - 4 Mpx ,
2560 x 1440 - 3.7 Mpx ,
2304 x 1296 - 3 Mpx ,
1920 x 1080 - 1080p ,
1280 x 960 - 1.3 Mpx ,
1280 x 720 - 720p |
| Lens: |
3.6 mm |
| View angle: |
84 ° (manufacturer data) 81 ° (our tests result) |
| Range of IR illumination: |
60 m |
| White light LED illuminator range: |
50 m |
| Min. illumination: |
0.006 Lux / F1.6 (color) 0.0006 F1.6 (B/W) |
| S/N ratio: |
> 56 dB |
| Memory card slot: |
Micro SD memory cards up to 256GB support (possible local recording) |
| Image compression method: |
H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Alarm inputs / outputs: |
1 / 1 |
| Audio: |
Microphone built-in, External microphone input Audio output Bi-directional audio streaming support Audio detection Compliance with the AAC standard |
| Main stream frame rate: |
20 fps @ 4 Mpx 25 fps @ 3.7 Mpx |
| Network interface: |
10/100 Base-T (RJ-45) |
| Network protocols: |
IPv4/IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P |
| WEB Server: |
Built-in |
| Max. number of on-line users: |
6 |
| ONVIF: |
21.12 |
| Mobile phones support: |
Port no.: 37777 or access by a cloud (P2P) Android: DMSS free application iOS (iPhone): DMSS free application |
| Default IP address: |
192.168.1.108 |
| Default admin user / password: |
admin / -
The administrator password should be set at the first start |
| Web browser access ports: |
80, 37777 |
| PC client access ports: |
37777 |
| Mobile client access ports: |
37777 |
| ONVIF port: |
80 |
| RTSP URL: |
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=0 - Main stream
rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1&subtype=1 - Sub stream |
| Main features: |
WDR - 120 dB - Wide Dynamic Range 3D-DNR - Digital Noise Reduction ROI - improve the quality of selected parts of image BLC/HLC - Back Light / High Light Compensation Possibility to change the resolution, quality and bit rate Motion Detection Configurable Privacy Zones Image rotation and mirror SMD PLUS - searching for an object classified as: human, motor vehicle IVS analysis : intrusion, crossing the line (tripwire) - classification of people and vehicles video tampering |
| Power supply: |
PoE (802.3af), 12 V DC / 510 mA |
| Power consumption: |
≤ 6.1 W @ 12 V DC ≤ 7.2 W @ PoE |
| Housing: |
Compact - Metal |
| Color: |
Black |
| "Index of Protection": |
IP67 |
| Vandal-proof: |
 |
| Operation temp: |
-40 °C ... 60 °C |
| Weight: |
0.71 kg |
| Dimensions: |
239 x 91 x 91 mm |
| Supported languages: |
Polish, English, Czech, French, Spanish, Dutch, German, Russian, Portuguese, Romanian, Turkish, Ukrainian, Hungarian, Italian |
| Manufacturer / Brand: |
DAHUA |
