| voice codecs | AAC, G.711Mu, G.711a, G.723, G.726 |
| audio input channels | 1 |
| audio output channels | 1 channels |
| Ethernet LAN ports (RJ-45) | 1 |
| Sensing distance (angular) | 44m |
| Observation distance (angular) | 18m |
| Recognition distance (angular) | 9m |
| Identification distance (angular) | 4m |
| Sensing distance (tele) | 146m |
| Observation distance (tele) | 58m |
| Recognition distance (tele) | 29m |
| Identification distance (tele) | 15 m |
| number of lenses | 1 |
| maximum opening | 1.5 |
| focal length range | 2.7 - 13.5mm |
| Closest focus distance | 0.8m |
| Height | 117.9mm |
| Weight | 950g |
| Diameter | 15.9cm |
| package weight | 1.2kg |
| Energy consumption | 11.8mA |
| Feeding | AC, DC, PoE |
| DC output voltage | 12 |
| AC input voltage | 24V |
| Operating temperature range | -30 - 60°C |
| Storage temperature range | -40 - 60°C |
| Operating Relative Humidity | 0 - 95% |
| Storage Relative Humidity | 0 - 95% |
| broadcast mode | multicast |
| ethernet | Yeah |
| Wifi | No |
| Supported network protocols | IPv4IPv6HTTPHTTPSTCPUDPARPRTPRTSPRTCPRTMPSMTPFTPSFTPDHCPDNSDDNSQoSUPnPNTPMulticastICMPIGMPNFSPPPoE802.1xSNMP |
| Bluetooth | No |
| ethernet interface type | fast ethernet |
| Quality of Service (QoS) support | Yeah |
| Number of users | 20 user(s) |
| bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Intelligent video analysis | Yeah |
| maximum resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.265, M-JPEG |
| supported video format | 1080p |
| frame rate | 30 ips |
| privacy mask | Yeah |
| noise reduction | Yeah |
| noise reduction technology | 3D noise reduction |
| Digital Wide Dynamic Range (DWDR) | Yeah |
| total megapixels | 2MP |
| Supported graphic formats | 352 x 240, 352 x 288, 640 x 480 (VGA), 704 x 480, 704 x 576, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Backlight Compensation (BLC) | Yeah |
| Date and time stamp | Yeah |
| overlay text | Yeah |
| Smart IR | Yeah |
| video broadcast | Yeah |
| Gain Control Type | Automatic/Manual |
| High Beam Compensation (HLC) | Yeah |
| Regions of interest (ROI) coding | Yeah |
| Symmetry/Mirror Effect | Yeah |
| Analog signal | PAL |
| integrated reading card | Yeah |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256GB |
| built-in HDD | No |
| privacy protection | Yeah |
| password protection | Yeah |
| Anti-flicker | Yeah |
| Beat | Yeah |
| Mirror | Yeah |
| digital watermark | Yeah |
| Motion sensor | Yeah |
| active tamper alarm | Yeah |
| Alert Notification Type | Email, Alert message with attached photos |
| HTTPS encryption | Yeah |
| Intelligent Video Surveillance System (IVS) Features | Abandoned object, Leak detection, Face detection, Intrusion, Object removed, People counting, Scene changes, Presence detection (tripwire) |
| Optical sensor size | 25.4 / 2.8mm (1 / 2.8") |
| sensor type | CMOS |
| number of sensors | 1 |
| progressive scan | Yeah |
| Web-based administration | Yeah |
| remotely operated | Yeah |
| Web navigator | Yeah |
| Lens angle of view, horizontal | 109° |
| Lens angle of view, vertical | 57° |
| Camera pan control | Yeah |
| Camera tilt control | Yeah |
| Inclination angle | 0 - 65° |
| tray reach | 0 - 355° |
| minimum lighting | 0.002 lux |
| rotation angle | 355° |
| white balance | Auto, Manual, Natural, Outdoor |
| shutter speed | 1/3 - 1/100000 s |
| Adjustable shutter speed | Automatic/Manual |
| number of cameras | 1 |
| product color | White |
| form factor | minidome |
| mounting type | Ceiling |
| IP code (International Protection) | IP67 |
| weather resistant | Yeah |
| shell material | Metal |
| IK code | IK10 |
| fog proof | Yeah |
| Night vision | Yeah |
| night vision distance | 40m |
| LED type | GO |
| Number of illumination LEDs | 3 |
| Guy | IP security camera |
| supported placement | indoor and outdoor |
| connectivity technology | Wire |
| day / night mode | Yeah |
| remote viewing | Yeah |
| Infrared cut filter | Yeah |
| Wide Dynamic Range (WDR) | Yeah |
| entry/exit alarm | Yeah |
