Mikrotik CSS610-1GI-7R-2S+OUT Netpower LITE 7R Reverse PoE Switch
Mikrotik CSS610-1GI-7R-2S+OUT Netpower LITE 7R Reverse PoE Switch
AED 716
AED 716 inclusive of VAT

Mikrotik CSS610-1GI-7R-2S+OUT Netpower LITE 7R Reverse PoE Switch

  • Model:  CSS610-1GI-7R-2S+OUT
  • SKU:                   203043
  • Condition:        New
  • Availability:      In Stock
AED 716 inclusive of VAT
Pay 4 interest-free payments of AED 179.00 , no interest/fees. Learn more
  • 1 year hassle free warranty claims
  • Delivery time is next working day, You can connect to support team to get exact delivery time.
Description - Mikrotik CSS610-1GI-7R-2S+OUT Netpower LITE 7R Reverse PoE Switch

An outdoor reverse PoE switch with Gigabit Ethernet and 10G SFP+ ports.

With netPower Lite 7R switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments. With this switch you won’t have to worry about power issues, as there are many options. netPower Lite 7R has 7 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 8 can power other PoE capable devices with the same voltage as applied to the unit. There is also a DC jack and a 2-pin terminal for alternative powering. The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower Lite 7R has a non-blocking throughput of 28 Gbps, switching capacity of 56 Gbps and forwarding rate of 41.7 Mpps.

Specifications

Details
Product code CSS610-1Gi-7R-2S+OUT
Switch chip model 88E6193X
Dimensions 304 x 212 x 71 mm
Operating System SwitchOS Lite
Storage size 64 KB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C

Powering

Details
Number of DC inputs 3 (DC jack, PoE-IN, 2-pin terminal)
DC jack input Voltage 12-57 V
2-pin terminal input Voltage 12-57 V
Max power consumption 29 W
Max power consumption without attachments 7 W
Cooling type Passive
PoE in Passive PoE
PoE in input Voltage 12-57 V

PoE-out

Details
PoE-out ports Ether8
PoE out Passive PoE
Max out per port output (input 18-30 V) 600 mA
Max out per port output (input 30-57 V) 450 mA

Ethernet

Details
10/100/1000 Ethernet ports 8
Number of 1G Ethernet ports with Reverse PoE (PoE-in) 7
Number of 1G Ethernet ports with PoE-out 1

Fiber

Details
SFP+ ports 2

Certification & Approvals

Details
Certification CE, EAC, ROHS
IP IP54
Read more
Specification - Mikrotik CSS610-1GI-7R-2S+OUT Netpower LITE 7R Reverse PoE Switch
Shipping Information
Varsai SKU 203043
Brand Mikrotik
Model CSS610-1GI-7R-2S+OUT
Warranty 1 Year   Hassle free warranty claims
Shipping Weight 1.99000000 kg
Shipping Dimensions 39.00000000 cm x 8.50000000 cm x 24.00000000 cm
